CBGシリーズ ギアポンプ
写真シリーズ
The CBG2 hydraulic gear pump is designed for systems that require stable flow, compact structure, and reliable pressure performance. Its internal structure uses axial clearance floating compensation, radial balance technology, and DU self-lubricating bearing support. This gear pump design helps improve working efficiency, reduce internal leakage, and extend service life under continuous hydraulic operation.
Compared with many other gear pump types, the CBG2 series is suitable for medium and high-pressure hydraulic systems. It offers multiple displacement options from 32 mL/r to 110 mL/r, allowing users to select the proper model according to system flow demand, motor speed, pressure requirement, and installation space.
The pump supports different shaft configurations, including plain key shaft, SAE spline shaft, rectangle spline shaft, and involute spline shaft. This makes it easier to match various engines, electric motors, transmissions, and hydraulic power units.
構成モデル/注文番号
CBGシリーズ ギアポンプ
クリップボードにコピー
↓設定されたパラメータ
パラメータはまだ設定されていません
設定が未完了でもお問い合わせを送信できます。完全な型番のコピーやサンプルダウンロードには、すべてのオプションを選択してください。
今すぐお問い合わせ
サンプルダウンロード
シリーズの利点
Product Advantages
1. High Volumetric Efficiency
The CBG2 gear pump provides volumetric efficiency of 92% or higher, helping reduce energy loss and improve hydraulic system performance.
2. Strong Pressure Capability
With 20 MPa rated pressure and 25 MPa maximum pressure, this hydraulic gear pump is suitable for demanding mobile machinery and industrial hydraulic equipment.
3. Optimized Gear Pump Design
The internal floating compensation structure and radial balance design help maintain stable performance, reduce wear, and improve pressure resistance.
4. Multiple Displacement Options
The CBG2 series covers 32, 40, 50, 63, 80, 100, and 110 mL/r displacement options, making it suitable for different hydraulic flow requirements.
5. Flexible Shaft and Mounting Choices
The pump can be supplied with different shaft types and square flange mounting options, helping equipment manufacturers match existing hydraulic system layouts.
6. Low Noise and Stable Operation
The compact structure, precision gear design, and balanced internal oil flow help reduce noise and vibration during operation.
7. Wide Application Compatibility
The CBG2 series can be used in many gear pump applications, including construction machinery, agricultural machinery, industrial vehicles, and hydraulic power units.
The CBG2 gear pump provides volumetric efficiency of 92% or higher, helping reduce energy loss and improve hydraulic system performance.
2. Strong Pressure Capability
With 20 MPa rated pressure and 25 MPa maximum pressure, this hydraulic gear pump is suitable for demanding mobile machinery and industrial hydraulic equipment.
3. Optimized Gear Pump Design
The internal floating compensation structure and radial balance design help maintain stable performance, reduce wear, and improve pressure resistance.
4. Multiple Displacement Options
The CBG2 series covers 32, 40, 50, 63, 80, 100, and 110 mL/r displacement options, making it suitable for different hydraulic flow requirements.
5. Flexible Shaft and Mounting Choices
The pump can be supplied with different shaft types and square flange mounting options, helping equipment manufacturers match existing hydraulic system layouts.
6. Low Noise and Stable Operation
The compact structure, precision gear design, and balanced internal oil flow help reduce noise and vibration during operation.
7. Wide Application Compatibility
The CBG2 series can be used in many gear pump applications, including construction machinery, agricultural machinery, industrial vehicles, and hydraulic power units.
技術仕様
| モデル | 変位 | 定格圧力 | 最大圧力 | 速度範囲 | 容積効率 | L1 | L | 重さ |
|---|---|---|---|---|---|---|---|---|
| CBG-2032- F * | 32mL/r | 20MPa | 25MPa | 800～3000r/min | ≥92% | 105.5mm | 184.5mm | 10.5kg |
| CBG-2040- F * | 40mL/r | 20MPa | 25MPa | 800～3000r/min | ≥92% | 107.5mm | 188.5mm | 11.5kg |
| CBG-2050- F * | 50mL/r | 20MPa | 25MPa | 800～3000r/min | ≥92% | 110.5mm | 194.5mm | 12kg |
| CBG-2063- F * | 63mL/r | 20MPa | 25MPa | 800～3000r/min | ≥92% | 114.5mm | 202.5mm | 12.6kg |
| CBG-2080- F * | 80mL/r | 20MPa | 25MPa | 800～3000r/min | ≥92% | 119.5mm | 212.5mm | 13.8kg |
| CBG-2100- F * | 100mL/r | 20MPa | 25MPa | 800～3000r/min | ≥92% | 125.5mm | 224.5mm | 14.8kg |
| CBG-2110- F * | 110mL/r | 20MPa | 25MPa | 800～3000r/min | ≥92% | 130mm | 230mm | 16.8kg |
応用産業
Application Scenarios
Construction Machinery
The CBG2 gear pump can be used in loaders, excavators, cranes, road rollers, and other construction equipment to provide hydraulic power for lifting, steering, working attachments, and auxiliary functions.
Forklifts and Material Handling Equipment
This hydraulic gear pump is suitable for forklifts, stackers, lifting platforms, and warehouse handling machines that require stable hydraulic flow and reliable pressure output.
Agricultural Machinery
The pump can be applied in tractors, harvesters, seeders, sprayers, balers, and other agricultural equipment for lifting, steering, and auxiliary hydraulic circuits.
Mining and Heavy-Duty Equipment
With a robust gear pump design and reliable pressure capacity, the CBG2 series is suitable for mining machinery, drilling equipment, and heavy-duty hydraulic systems.
Sanitation and Municipal Vehicles
The CBG2 gear pump can be used in garbage trucks, sweepers, road maintenance vehicles, and other municipal equipment requiring hydraulic power transmission.
Hydraulic Power Units
This pump is also suitable for hydraulic power packs and industrial hydraulic stations where compact size, stable output, and high efficiency are required.
